In vitro Micro Propagation of Soybean (Glycine max) BARI-5 Variety



Nadira Begum1, Elina A. Zenat1, Mohammad K.I. Sarkar2, *, Chapol K. Roy1, John L. Munshi1, Miskat A. A. Jahan1
1 Bangladesh Council of Scientific and Industrial Research (BCSIR), Dhaka, Bangladesh
2 Independent University,(IUB), Dhaka, Bangladesh


Article Metrics

CrossRef Citations:
0
Total Statistics:

Full-Text HTML Views: 585
Abstract HTML Views: 395
PDF Downloads: 209
ePub Downloads: 180
Total Views/Downloads: 1369
Unique Statistics:

Full-Text HTML Views: 379
Abstract HTML Views: 229
PDF Downloads: 142
ePub Downloads: 120
Total Views/Downloads: 870



© 2019 Begum et al.

open-access license: This is an open access article distributed under the terms of the Creative Commons Attribution 4.0 International Public License (CC-BY 4.0), a copy of which is available at: (https://creativecommons.org/licenses/by/4.0/legalcode). This license permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

* Address correspondence to this author at the Independent University, Bangladesh (IUB); Tel: +8801711230892; Emails: khairul@iub.edu.bd and kisarkar1981@gmail.com


Abstract

Introduction:

The present research work was undertaken with a view to developing a suitable protocol for in vitro plant regeneration of economically important plant (Glycine max) (Bangladesh Agricultural Research Institute BARI- 5) variety, via both direct and indirect organogenesis from in vitro grown seedlings.

Methods:

For micropropagation explants were cultured on MS and half strength Murashige and Skoog (MS) medium supplemented with various plant growth regulators (cytokinins and auxins). In the present study for inducting of callus, among 3 different hormone combinations, the suitable medium was 3.32 mg/L 2, 4-D containing MS medium and the callus was deep green in color. Different type of media like MS, 1/2 MS and MS with different (6-Benzyl Amino Purine) BAP concentration was used for seed germination of Glycine max. 100% of seed germination was observed in MS +1 mg/L BAP containing the medium.

Results:

In the present investigation, different concentration of cytokinins and auxins{BAP, 2, 4-D, and Naphthalene Acetic Acid (NAA)} were used individually or in combinations with MS medium to observe their effect on multiple shoot regeneration from the cotyledonary nodal segment. 100% shoot formation from cotyledonary nodal segment was recorded in 1.5 mg/L BAP and 0.15 mg/L BAP + 0.025 mg/L NAA containing MS medium, the best number of shoot was 10.9±2.0 found in MS + 1.5 mg/L BAP containing medium and highest length of shoot was 2 cm recorded in 1.5 mg/L BAP + 0.3 mg/L (different concentrations of Giberrellic acid) GA3 containing MS medium. In addition, for root induction in vitro raised well developed and elongated shoots were excised and cultured on MS and 1/2 MS medium supplemented with various concentration of Indole-3-Butyric acid (IBA). It was observed that MS medium containing 0.1 mg/L IBA and 1/2 MS medium containing 0.25 mg/L IBA was optimal for root induction. In which 100% shoots rooted well within 13 days of culture. The highest average number of roots per shoot was 6 recorded in MS +0.5 mg/L IBA containing the medium and highest average length of root was 8 cm recorded in 0.1 mg/L IBA containing MS medium.

Conclusion:

The most effective surface sterilization treatment for explants of Glycine max has been found in 0.1% HgCl2 solution for 15 minutes.

Keywords: Micro propagation, Regeneration, MS medium, Glycine max, Soybean, Seed germination.



1. INTRODUCTION

Soybean (Glycine max) belonging to the family Leguminosae constitute one of the oldest cultivated crops of the tropical and sub-tropical regions, and one of the world's most importantsources of protein and oil. Soybeans are probably the most important oilseed legume which has its origin in Eastern Asia, mainly China. The cultivar Glycine max is thought to be derived from Glycine ussuriensis and Glycine tomentosa which grow wild in China and can be found in great quantities in Asian countries such as Japan and Indonesia [1].

The seeds vary in shape and color depending on the cultivar. In shape, they can be spherical to flatten while the color varies from white, yellow and brown to black. Also, the chemical compositions of each variety of soybeans differ from each other. As a result of high protein content in soybean, it can be used as a substitute for expensive meat and meat products [2].

Soybean is particularly varied unique for a different reason and hence classified as a valuable and economical agricultural commodity. In the first instance, it possesses agronomic characteristics with its ability to adapt to a wide range of soil and climate and its nitrogen-fixing ability. This makes it a good rotational crop for use with high nitrogen consuming crops such as corn and rice. Secondly, soybean unique chemical composition on an average dry matter basis is about 40% of protein and 20% of the oil. This composition makes it rank highest in terms of protein content among all food crops and second in terms of oil content after peanut (48%) among all food legumes. Furthermore, soybean is a very nutritious food crop [3].

Furthermore, soybean seeds are also a major source of excellent health benefit products for example antioxidants, omega-3 fatty acids, amino acids, phytoestrogens, and foliate. Soybean is moreover utilized in a variety of processed nutritional food products (soy milk, soy cheese, yogurt, and ice cream) as well as considered as nutritionally comparable to meat. Soybean oil is utilized for lots of human food products as well as cooking oil and has many manufacturing industrial uses including soaps, oils, paints, cosmetics, plastics, clothing, and solvents. In recent times, soybean is also utilized as biofuel crop to run into worldwide energy demands putting important pressure on crop production for food. In addition, global climate change presents threats to our food supply.

Soybean is an allopolyploid with three rounds of whole genome duplication [4, 5]. In recent times, there has been a major work in thoughtful the genome of soybean by undertaking large-scale genome sequencing, microarray, expressed sequence tag sequencing, and transcriptome analyses [6, 7]. Moreover, comprehensive studies on synteny, Quantitative Trait Locus (QTL) mapping, and comparative genomics have improved our knowledge on soybean as well as closely related legumes of financial significance [8-11].

Soybean has widespread adaptability with a huge quantity of cultivars showing variability to flower in response to day length and temperature. Thus, soybean cultivars have been divided into thirteen maturity groups based on the photoperiod and temperature requirements for flowering.

Soybean, originating in China, at present is a most important crop in North and South America as well as Asia. Soybean production has improved fivefold during the past four decades making it the most important protein, as well as oil crop globally [4] and this growth are predicted to continue due to increasing demand for food, feed, and fuel. Significant efforts have been made to increase soybean through conventional breeding. However, classical breeding programs for soybean are limited by its self-pollination ability [12]. Therefore, there is an essential for transgenic approaches to its development. Efficient plant regeneration procedure is the prerequisite for successful application of genetic transformation technology. There has been an ongoing effort for enhancing the plant regeneration potential of soybean via either organogenesis or somatic embryogenesis. Organogenesis based regeneration is attractive due to an abundant and convenient supply of explants. Earlier reports have tried using different explants such as cotyledonary node [13, 14], whole cotyledonary node [15], epicotyl and primary leaves [16, 17], primary leaf nodes [18], and hypocotyls [12, 19–22].

We aim to develop genetic transformation technology for commercial soybean varieties by identifying the most optimal way to regenerate shoots from different soybean explants and evaluate whether shoots regeneration capacity is related to the maturity grouping of the soybean cultivars. It is well established that crop plant regeneration ability is tissue and genotype dependent. Hence, we compared the regeneration ability of three different soybean explants from nine soybean cultivars. This is the first report of in vitro plant regeneration of commercially grown Bangladesh soybean varieties. The protocol developed would assist in developing a genetic transformation system for these soybean varieties.

2. MATERIALS AND METHODS

The experiment was conducted at Biological Research Division of Bangladesh Council of Scientific and Industrial Research (BCSIR) Dhanmondi, Dhaka. Soybean Seeds (Glycine max) BARI-5 variety were collected from Bangladesh Agricultural Research Institute (BARI), Gazipur.

Seeds were washed thoroughly under running tap water, presoaked in liquid detergent for about 30 min, wiped with cotton and dipped in 70% (v/v) ethanol for 1 min. They were then surface sterilized with 0.1% (w/v) mercuric chloride for 5 min, followed by five times rinse with sterile distilled water under laminar air flow cabinet.

Cotyledonary nodal explants from aseptically grown mature seeds of Glycine max were cultured on MS medium [23] following normal in vitro culture procedures [24] for adventitious shoot regeneration. Half strength MS medium was used for in vitro rooting. All media were supplemented with 30 g/L sucrose, 7 g/L agar (Difco) and dispensed into 15x150 mm culture tubes and 250 ml conical flasks. The pH of the media was adjusted to 5.8 before autoclaving at 121°C for 20 min. The cultures were incubated for a 16 h photoperiod at 24 ± 20°C under a fluorescent light.

The surface sterilized explants were sized to 1.0 - 1.5 cm length containing a single node with an axillary bud or a shoot tip with an apical bud. Explants were placed vertically on the culture medium. The new shoots induced from the in vitro cultures were further used as explants for shoot regeneration. MS with different concentrations of hormone was used for shoot proliferation and shoot regeneration and half strength MS was used for in vitro root induction. All media were supplemented with 30 g/L sucrose, 7 g/L agar In vitro Shoot Proliferation and Plant Regeneration and dispensed into 15 × 150 mm culture tubes and 250 mL conical flasks. The pH of the media was adjusted to 5.8 before autoclaving at 1.9 kg/cm2 pressure at 121°C for 20 min. The cultures were incubated for a 16 hr photoperiod at 24 ± 2°C under 1200 lux/m2 fluorescent light. Shoot proliferation from shoot tip and nodal explants was obtained in two separate sets of experiments. In the first experiment 0.5 - 2.0 mg/L BAP and 0.5 - 2.0 mg/L Kn were incorporated into MS to select the best cytokinin for the response of shoot induction. In the second set, combination of BAP (0.5 - 2.0 mg/L) with NAA (0.1 - 0.5 mg/L) and BAP (0.5 - 2.0 mg/L) with IAA (0.1 - 0.5 mg/L) were assessed for shoot multiplication. A number of new shoot proliferation of each culture was recorded after every week of inoculation. For in vitro rooting, individual shoots (3 - 5 cm long) were excised from the proliferated shoot cultures and implanted onto half strength MS media with different concentrations and combinations of NAA, IBA and IAA. The rooted plantlets were taken out from the culture tubes, washed to remove agar gel adhered to the roots and transplanted to plastic pots with soil and compost (1: 1) for hardening. The plantlets were kept in a poly chamber at 80% relative humidity, 32 ± 2°C for a 12 hr photoperiod under 1500 lux.

The materials and methods used throughout the investigation in vitro micropropagation are described below under the following heads and subheads.

2.1. Sterility and Surfactant

Ethyl alcohol (70%) was used to wipe surfaces of working areas, to rinse hand, to dip instruments with or without subsequent flaming, 0.1% Mercuric chloride (HgCl2) was used to disinfect the plant tissues. Jet powders (detergent) were also used as detergent and disinfectant.

2.1.1. Sterilization

Finally, the culture media were sterilized by autoclaving at 15 Ibs/inch2 pressure for 15 minutes at 121°C. Then the vessels with the medium were allowed to cool as vertically and then marked with a permanent marker pen to indicate specific hormonal supplements and stored in the culture room for ready to use.

2.2. Preparation of Plant Material and Sterilization of Seed

In the present investigation, the cotyledonary nodal segment of in vitro grown seedling of Glycine max (BARI-5 variety) was used as explants. For the primary establishment of in vitro culture, surface sterilization of seed of Glycine max (BARI – 5 variety) was essential because the nutrient media which are used in tissue culture techniques are most suitable for the growth of microbes also. That's at first freshly collected seeds were washed thoroughly detergent for 4-5 times under running tap water. After that, they are taken in laminar air flow cabinet and dipped in 0.1% HgCl2 solution for 5 minutes with constant shaking to ensure contaminant-free cultures. Then seeds were washed with 70% ethanol for 1 minute. Lastly, the seeds were rinsed with autoclaved distilled water for 3-4 times in order to remove the last drop of HgCl2. The explants were then put in a sterile conical flask for inoculation (Fig. 1).

2.3. Inoculation of Explants

Before starting the inoculation programmed the laminar airflow’s Floor was cleaned with 70% ethanol. After then it was put on for 30 minutes. All the inoculations and aseptic manipulations were carried out in front of laminar air flow cabinet. The sterilized dissecting instruments were brought to the laminar air flow and before every use; the above instruments were dipped into absolute alcohol and flamed over a spirit lamp several times. Other sterilized requirements like a petri dish, distilled water, blotting paper were also used for the procedure. Before starting inoculation hands were repeatedly washed thoroughly by soap and made sterile by spraying 70% ethanol. For surgical operations, sufficient care was taken as usual to obtain possible contamination-free conditions. Sterilized seeds were collected in a sterilized petri dish and remove the thin surface layer of seeds so that embryo can germinate properly and quickly. Then the prepared seeds were carefully inoculated in culture vessels containing agar gelled nutrient medium supplemented with different combination and concentrations of hormones. Special care was taken so that the part of seeds must penetrate in the medium but not deep into the medium. The mouth of the culture vessels plugged tightly inside laminar air flow cabinet in presence of spirit lamp and marked by a permanent marker with inoculation date. Then the flasks are ready for incubation and observation.

2.4. Incubation

The inoculated culture flasks were incubated in a growth chamber providing a special culture environment. The culture flasks were placed on the shelves of the cupboard in the growth chamber. Which was illuminated by 40 watts white fluorescent tubes fitted at a distance at 30- 40 cm from the culture shelves? The cultures were maintained at 25 ±21 °C with air cooler under the fluorescent light intensity of 28-34 molm-2s-1. The photoperiod was maintained generally 16 hours light and 8 hours dark by an automated timer. The culture vessels were checked periodically to note the response.

2.5. Subculture for Shoot Multiplication and Elongation

After two weeks of inoculations, small plant was transferred aseptically to a sterile petri dish and was cut into small pieces of different part(like cotyledonary nodal segment having auxiliary buds, shoot tip node enter node etc.) by a sterile scalpel. Then cotyledonary nodal segment was transferred to freshly prepare medium containing different combinations of hormone supplement for multiplication and elongation of shoots. After every 3 weeks, multiple shoots were placed in root inducing media. Rest of the ex-plants with small multiple shoot buds and leafy structure were again cut into convenient sizes and inoculated in optimum hormonal supplemented media.

2.6. Subculture for Rooting

In this stage, the shoots were excised from the vessels of multiplication media and cultured individually in freshly prepared rooting media containing different concentrations and combinations of auxins.

3. RESULTS

In the present investigation, the cotyledonary nodal segment of in vitro grown seedling of Glycine max (BARI-5variety) was used as explants. Details of the result so far obtained from each of the experiments are described under following heads:

3.1. Standardization of Surface Sterilization of Explants

Surface Sterilization of explants was accomplished with an aqueous solution of mercuric chloride (HgCl2). Considering the problem of contamination, different concentration of HgCl2 was used and the explants were treated in different periods of time.

3.1.1. Surface Sterilization of Seed of Glycine Max (BARI-5 Variety)

A concentration of HgCl2 solution up to 0.2% and the treatment period of 20 minutes did not harm viability due to the hard seed coat. Treatment with 0.05% HgCl2 solution for 20 minutes, 0.1% HgCl2 solution for 10 to 20 minutes and 0.2% solution for 08 to 20 minutes resulted in 100% contamination free seeds.Treatment with 0.05% HgCl2 solution for 06 and 08 minutes showed 50% contamination free seeds.Whereas treatment with 0.05% and 0.1% HgCl2 solution for less than 10 to 20 minutes showed 100% contamination free seeds. In the present experiment, the seeds were treated with the different concentration of HgCl2. 100% of cultures were found contamination free without injury when treated with 0.1% HgCl2 for 15 minutes. (The summarized results of these experiments are shown in Table 1.

3.2. Effect of Different Medium on Seed Germination of Glycine Max (BARI-5 Variety)

In this experiment, a different type of media like MS, 1/2 MS and MS with different BAP concentration was used for seed germination of Glycine max. 100% seed germination was recorded in MS + 1 mg/L BAP containing a medium highest average length of shoot per culture was record 11cm in MS media.

Lowest percentage (70%) of seed germination was recorded in MS medium lowest average length of shoot per culture was recorded 2cm in MS + 0.5 mg/L BAP containing media. (The summarized results of these experiments are shown in Table 2.

3.3. Shoot Multiplication

Soybean seeds were cultured in MS [23] medium supplemented with different concentration of growth regulators (Cytokinins and Auxins) either singly or in combination to find out a suitable medium for shoot multiplication. Data were taken for the percentage of cultures respond to the average number of shoot per culture, average length of shoot and root formation. All data were collected after 23 days of culture. The results were discussed under the following separate heads:

3.4. Effect of Different Concentration of BAP alone in MS Medium on Multiple Shoot Development of Glycine Max (BARI -5 Variety).

In this experiment, BAP was used to find out its effect on shoot development form the cotyledonary nodal segment of Glycine max (BARI -5 varieties. Percentage of culture responded to multiple shoot formation in a different level of BAP varied considerably.

100% of multiple shoot development was recorded in 1.5 mg/L BAP containing media, on the other hand, the lowest percentage of multiple shoot development was recorded in 0.5 mg/L BAP containing the medium. Highest average number of shoot per culture was recorded at 23 days of culture. The highest average number of shoot per culture was 10.9 ± 2.0 recorded in 1.5 mg/L BAP containing media and the highest average length of shoot per culture was recorded 1cm in 1.5 mg/L BAP containing media. On the other hand lowest average number of shoot per culture was recorded 5.3 ± 0.34 in 0.5 mg/L BAP containing media and the lowest average length of shoot per culture was recorded 0.5cm in 0.5 mg/L BAP containing media. (The summarized results of these experiments are shown in Table 3.

3.5. Effect of Different Concentration of BAP in Combination with GA3 in MS Medium on Multiplication and Elongation of the Shoot

The highest percentage (76%) of culture has recorded in media containing 1.5 mg/L BAP + 0.3 mg/L GA3. Whereas lowest percentage (47%) of was respond in 1.0 mg/L BAP + 0.2 mg/L containing medium. In the experiment, the highest average number of shoot per culture was 7.6 ± 20.56 in the medium containing 1.5 mg/L BAP + 0.3 mg/L GA3. The highest average length of the shoot was 2cm observed in the same medium. As well as the lowest average number of shoot per culture was 4.7 ± 0.39 in 1.0 mg/L BAP + 0.2 mg/L GA3 containing the medium. The lowest average lenth of the shoot was observed 0.5 cm in medium containing1.0 mg/L BAP + 0.2 mg/L GA3. The most effective best media formulation 1.5 mg/L BAP + 0.3 mg/L GA3. (The summarized results of these experiments are shown in) Table 4.

3.6. Effect of Different Concentration of BAP in Combination with NAA in MS Medium on Induction Multiple Shoots

100% of culture has responded in medium containing 1.0 mg/L BAP + 0.025 mg/L NAA. Whereas, lowest percentage (32%) was observed in 0.05 mg/L BAP + 0.05 mg/L NAA containing medium. The highest average number of shoot per culture was observed 10 ± 0.56 in the medium containing 0.15 mg/L BAP + 0.025 mg/L NAA and the highest average lenth of shoot was 1cm found in medium containing 0.15 mg/L BAP + 0.025 mg/L NAA. As well as lowest average number of shoot per culture was 1.6 ± 0.36 found in medium containing 0.05 mg/L BAP + 0.05 mg/L NAA. As well as, the lowest average lenth of shoot was 0.5cm found in medium containing 0.05 mg/L BAP + 005 mg/L NAA. The most effective best media formulation was 0.15 mg/L BAP + 0.025 mg/L NAA. (The summarized results of these experiments are shown in) Table 5.

3.7. The best Result from Seed and Shoots

From the above experiments, it was found that among all the growth regulators-

  • MS + BAP 1 mg/L showed the 100% of seed germination.
  • MS + BAP 1 mg/L and 0.15 mg/L BAP + 0.025 mg/L NAA containing medium showed the 100% of multiple shoot development.
  • The highest average number of multiple shoots 10.9 ± 2.0 was observed in MS + 1.5 mg/L BAP containing the medium.
  • The highest average length of the shoot was 2cm observed in MS + 1.5 mg/L BAP containing the medium.

3.8. Callus Induction

Induction of callus is a novel way to have soma clonal variants. Regarding this MS media supplemented with different kinds of hormones at different concentration were used to initiate callusing. Rapid induction of callus was seen in the seedling explants than those of mature plants. It was found that for best callus induction, proper contact of the explants with the medium was absulately essential.

3.9. Effect of Different Concentration of BAP alone in MS Medium on Callus Induction Fromcotylidonary Nodal Segment of Glycine Max (BARI -5 Variety).

In the present study, 90% callus induction response was obtained in MS medium supplemented with 2.0 mg/L BAP. 100% of callus was obtained in 1.5 mg/L BAP containing the medium. The color of callus was deep green. (The summarized results of these experiments are shown in) Table 6.

3.10. Effect of Different Concentration of BAP in Combination with GA3 in MS Medium on Callus Induction from the Cotyledonary Nodal segment of Glycine Max (BARI -5 Variety).

In the present study, 40% callus induction response was obtained in MS medium supplemented with 0.5 mg/L BAP + 0.2 mg/L GA3. The highest percentage (70%) of callus is obtained in 1.0 mg/L BAP + 0.2 mg/L GA3 containing the medium. The color of the callus was black. (The summarized results of these experiments are shown in) Table 7.

3.11. Effect of Different Concentration of 2,4-D Alone in MS Medium on Callus Induction from the Cotyledonary Nodal Segment of Glycine Max (BARI -5 Variety).

The present study showed a 90% callus induction on MS medium supplemented with 0.73 mg/L 2,4-D. 100% of callus was obtained in MS + 3.32 mg/L 2,4-D containing the medium. The color of callus was deep green . The summarized results of these experiments are shown in Table 8.

3.12. Effect of Different Concentration of 2,4-D in Combination with NAA in MS Medium on Callus Induction from the Cotyledonary Nodal Segment of Glycine Max (BARI -5 Variety).

In the present study, the highest percentage (25%) of callus is observed in 0.73 2,4, D + 0.69 mg/L NAA containing the medium. The color of callus was light green. (The summarized results of these experiments are shown in) Table 9.

3.12.1. The Best Result from Callus

From the above experiments, it was found that among all the growth regulators-

  • MS + 3.32 mg/L 2,4-D and MS + 1.5 mg/L BAP containing medium showed 100% of callus development.

3.13. Rooting of in vitro Regenerated Shoots

Shoot development as well as rooting of regenerated shoots is especially important for establishing tissue cultured derived plants.The regenerated shoots did not produce root spontaneously. For this purpose, in vitro raised well developed and elongated shoots were excised from the clamp of multiple shoots and they were cultured for rooting. In this experiments, for in vitro rooting MS and half strength MS medium was supplemented with different concentration of IBA.

3.14. Effect of Different Concentration of IBA Alone in MS Medium on Rooting of in vitro Regenerated Shoot of Glycine Max (BARI -5 Variety).

In this experiment, IBA was used in the concentration of 0.1-4.0 mg/L. It was observed that the best response for rooting was obtained in MS + 0.1 mg/L IBA containing the medium. In this composition 100%, excised shoots were rooted well within 13 days. The highest average number of roots per shoot was 6 found in MS + 0.5 mg/L IBA containing the medium. The highest average length of root was 8 found in MS + 0.1 mg/L IBA containing the medium. (The summarized results of these experiments are shown in) Table 10.

3.15. Effect of Different Concentration of IBA Alone in 1/2 MS Medium on Rooting of in vitro Regenerated Shoot of Glycine Max (BARI -5 Variety).

In this experiment, IBA was used in the concentration of 0.1-0.5 mg/L. It was observed that the best response for rooting was obtained in 1/2 MS + 0.25 mg/L IBA was used. 100% excised shoots were rooted well within 13 days in the same medium. The highest average number of roots per shoot was 2 and the highest average length of root was 1.5cm observed in 1/2 MS + 0.25 mg/L IBA containing medium. (The summarized results of these experiments are shown in) Table 11.

3.15.1. The Best Result from Root

From the above experiments, it was found that among all the growth regulators-

  • MS + 0.1 mg/L IBA containing medium and 1/2 MS + 0.25 mg/L IBA containing medium showed 100% of root development from multiple shoots.
  • The highest average number of root per multiple shoots was 6 recorded in1 MS + 0.5 mg/L IBA containing medium.
  • The highest average length of the shoot was 8cm observed in MS + 0.1 mg/L IBA containing the medium.

3.16. Surface Sterilization of Seed of GLycine Max (BARI-5 variety).

The present investigation was aimed to develop a suitable protocol for in vitro regeneration of diseases free culture of economically important plant GLycine max (BARI-5variety). HgCl2 is widely applied sterilizing agent in the field of tissue culture because of its oxidizing nature to kill the microorganisms. Bacterial and fungal infections can be eliminated accurately by proper immersion time of explants in the HgCl2 solution. Furthermore, the concentration of HgCl2 solution is equally important to obtain sterile ex-plants. In the present experiment the seed of GLycine max (BARI-5 variety). Were treated with different conc. of HgCl2 solution, 100% of cultures were found contamination free without injury when treated with 0.1% HgCL2 for 15 minutes. Whereas [25] following a 5 min. Sterilization treatment of soybean seed in 0.2% aqucous swolution of HgCl2.

Table 1. Surface sterilization of seed of Glycine max (BARI-5 variety).
HgCl2 Treatment in Minutes Number of Seed Sterilized Concentration of Mercuric Chloride (HgCl2)
0.05% 0.1% 0.2%
No. of Concentration Free Seed No. of Concentration Free Seed No. of Concentration Free Seed
5
6
7
8
9
10
15
20
100
100
100
100
100
100
100
100
-
-
-
-
-
20
73
100
-
47
66
87
92
100
100
100
50
62
85
100
100
100
100
100
Table 2. Effect of different medium on seed germination of Glycine max (BARI-5 variety).
Media Used No. of Seed Inoculated % of Seed Germinated Days Required for Germination The Average Length of Shoot (cm)
MS
1/2MS
MS + BAP0.5mg/l
MS + BAP 1mg/l
MS + BAP1.5mg/l
5
5
5
5
5
70
73
90
100
95
7
7
6
6
6
11
4
2
2.5
2.3
Table 3. Effect of different concentration of BAP alone in MS medium on multiple shoot development of Glycine max (BARI-5 variety).
Media Content mg/l No. of Cotylidonary Nodal Segment Inoculated Average No. of Multiple Shoots (mean)± The Average Length of Multiple Shoots (cm) % of Multiple Shoots
MS + BAP0.5
MS + BAP 1.5
MS + BAP 2
10
10
10
5.3±0.34
10.9±2.0
7±1.34
0.5
1
0.5
53
100
70
Table 4. Effect of different concentration of BAP alone in combination with GA3 in MS medium on multiplication and elongation of the shoot.
Media Content mg/L No. of Cotyledonary Nodal Segment Inoculated Average No. of Multiple Shoots (mean)± SE The Average Length of Multiple Shoots (cm) % of Multiple Shoots
BAP + GA31.0+0.2
BAP + GA31.0+0.3
BAP + GA31.5+0.3
10
10
10
4.7±0.39
5.4±0.56
7.6±0.56
0.5
1
2
47
54
76
Table 5. Effect of different concentration of BAP in combination with NAA in MS medium on induction of multiple shoots.
Media Content mg/L No. of Cotylidonary Nodal Segment Inoculated Average no. of Multiple Shoots (mean) ± SE The average Length of Multiple Shoots (cm) % of Multiple Shoots
BAP + NAA0.05+0.05
BAP + NAA 0.1+0.05
BAP + NAA0.15+0.05
BAP + NAA0.2+0.05
BAP + NAA0.05+0.025
BAP + NAA0.1+0.025
BAP + NAA0.15+0.025
BAP + NAA0.2+0.025
5
5
5
5
5
5
5
5
1.6±0.36
3±0.66
2±0.18
2±0.18
2±0.18
2±0.18
10±0.56
4±0.63
0.5
1
0.5
0.5
0.5
0.5
1
1
32
60
40
40
40
40
100
80
Table 6. Effect of different concentration of BAP alone in MS medium on callus induction from the cotyledonary nodal segment of Glycine max (BARI-5 variety).
Media Content mg/L No. of Cotylidonary Nodal Segment Inoculated Days Reruired for Callus Induction % of Callus Induction Color of Callus
          MS + BAP0.5
          MS + BAP1.5
          MS + BAP2
5
5
5
28
28
28
50
100
90
Lightgreen
Deep green
Coffee
Table 7. Effect of different concentration of BAP in combination with GA3 in MS medium on callus induction from the cotyledonary nodal segment of Glycine max (BARI-5 variety).
Media Content mg/L No. of Cotylidonary Nodal Segment Inoculated Days Required for Callus Induction % of Callus Induction Color of Callus
          BAP + GA30.5+0.1
          BAP + GA30.5+0.2
          BAP + GA31.0+0.2
5
5
5
23
23
23
30
40
70
Yellow
Light green
Black
Table 8. Effect of different concentration of 2,4-D in combination in MS medium on callus induction from the cotyledonary nodal segment of Glycine max (BARI-5 variety)
Media Content mg/L No. of Cotylidonary Nodal Segment Inoculated Days Required for Callus Induction % of Callus Induction Color of Callus
          MS + 2,4-D0.73
          MS + 2,4-D1.99
          MS + 2,4-D3.32
          MS + 2,4-D4.64
5
5
5
5
14
14
14
14
90
40
100
50
Green
Light green
Deep green
Light green
Table 9. Effect of different concentration of 2,4-D in combination with NAA in MS medium on callus induction from the cotyledonary nodal segment of Glycine max (BARI-5 variety).
Media Content mg/L No. of Cotylidonary Nodal Segment Inoculated Days Required for Callus Induction % of Callus Induction Color of Callus
2,4D+NAA
0.73+0.69
2,4D+NAA
1.99+1.76
2,4D+NAA
3.32+2.83
5
5
5
12
12
12
25
10
5
Light green
Light green
Creamy
Table 10. Effect of different concentration of IBA alone in MS medium on rooting of in vitro regenerated shoot of Glycine max (BARI-5 variety).
Media Content mg/L No. of Shoot Inoculated % of Root Per Cultured Shoot Days Required for Rooting Average No. of Root Per Shoot The Average Length of The Root (cm)
MS + IBA0.1
MS + IBA0.25
MS + IBA0.5
MS + IBA1
MS + IBA2
MS + IBA3
MS + IBA4
5
5
5
5
5
5
5
100
70
90
70
50
50
50
13
13
13
13
13
13
13
3
2
6
3
1
1
1
8
0.5
0.5
4
0.001
0.002
0.001
Table 11. Effect of different concentration of IBA alone in ½ MS medium on rooting of in vitro regenerated shoot of Glycine max (BARI-5 variety).
Media Content mg/L No. of Shoot Inoculated % of Root Per Cultured Shoot Days Required for Rooting Average No. of Root Per Shoot The average Length of The Root (cm)
1/2MS + IBA0.1
1/2MS + IBA0.25
1/2MS + IBA0.5
1/2MS + IBA1
5
5
5
5
70
100
90
60
13
13
13
13
1
2
1.5
1
0.5
1.5
1
1
Fig. (1) . Callus induction from the cotyledonary nodal segment of Glycine Max (BARI- 5 varieties) after culture.

3.17. Callus Induction

Callus inducting is a prerequisite on the way to regenerate soma clonal variation because during cell division of callus in artificial condition different types of genetic changes occur and this ultimately contributed to the regenerated plants. As a result, a lot of variation may be found in the plants regenerated from a single callus population. Callus is actively dividing nonorganized tissue of undifferentiated and differentiated cells often developing from injury (wounding) or in tissue culture [26]. Callus formed during in vitro culture has some similarity to in tissue arising in vitro injury plants (so called wound callus). However, there is a difference in morphology. Cellular structure growth and metabolism between callus derived through tissue culture and natural wound cells. Now it has been established that any tissue can be changed into a callus. If cultured on a suitable defined medium under controlled conditions [27] demonstrated hormonal control of differentiation and laid the foundation of clonal propagation of plants through tissue culture techniques. Exogenous supply of auxins and often in combination with cytokinins to medium is essential but many other factors such as light temperature. Humidity and others are also important for callus production [26]. in the present study. A variable amount of callus produced from cotylidonary nodal segment when they were cultured in the presence of BAP, 2.4-D, NAA singly or in combination. It was observed that callus was light green. White black deep green and coffee color. Callusing was best (100%) on medium supplemented with MS + 3.32 mg /L 2.4-D. (table- 8). Thus indirectly organogenesis took place [28] produced callus from mature half seed' s nodal segment using different combinations of BAP and 2.4- bichlorophenoxy acetic acid (2.4-D). The callus produced a number of plants when cultured on Gamborg B5 medium supplemented with BAP while the addition of 2.4-D enhanced somatic embryo production (Fig. (2).

Fig. (2). Callus induction from the cotyledonary nodal segment of Glycine Max (BARI- 5 varieties) after 15 days.

3.18. Organogenesis of Glycine Max

The most important development in culture media was the incorporation of growth regulators like auxins and cytokinins. In present study MS and 1/2 strength of MS media were used for callus induction shoot multiplication and root formation from the cotyledonary nodal segment of Glycine max (BARI-5 variety). Various hormonal supplements namely BAP, NAA, 2.4-D IBA, GA3 and their various combinations were used in these media.

3.19. Multiple Shoot Formation

In the present study, MS media supplemented with various hormones namely NAA, BAP, GA3 and their various combinations were used for shoot multiplication. In this study, it was observed that the highest number of multiple shoots was 10.9 ±2.0 initiates in 1.5 mg/L BAP containing the medium and highest average length of multiple shoots 2cm was found in 1.5 mg/L BAP + 0.3 mg/L GA3 containing the medium. BAP provided smaller length of proliferated shoots in contrast to shoots number [29] found that 86.7% cotylidonary nodes induced shoots with an average of treatment for shoot induction was carried out in MS salts and B5 vitamins (MS B5) medium supplemented with 11.1Um BAP and 0.5Um a-NAA [30] found that soybean cultivars ` Pungsannamulkong ` and `llpumgeomjeongkong` produced adventitious shoots when BAP was used in the media. Whereas `Alchangkong produced shoot when treated with zeatin and IAA [31] were able to get multiple shoot bud formation from cotyledonary nodes on medium containing high concentrations of 6-benzyl aminopurine (BAP) but bud growth improved when the cultures were transferred to low concentrations of BAP. However, the addition of thidiazuron (TDZ) [12, 32] with BAP has been reported as a better combination for embryo formation from cotyledonary nodal ex-plants Fig. (3).

Fig. (3). Multiple shoots regeneration from the cotyledonary nodal segment of Glycine Max (BARI- 5 varieties).

3.20. Rooting of in vitro Regenerated Shoot

Auxins are considered as the effective plant growth regulators which accelerate the processes of root induction and development by differentiation of vascular bundles. They promote rooting in the plants through changes in the biochemical system of the plants [33]. Among various auxins. IBA is known to stimulate rooting more effectively due to its week toxicity and greater stability for induction of roots where as [31] reported that Soybean plants were produced by rooting of tissue culture shoots on a basal medium without auxins. In the present study different concentration of IBA were used for in vitro rooting well-developed multiple shoots when attaining considerable height were shifted to half strength MS medium containing a different concentration of IBA. In the present study among the different concentration of hormone best rooting response was 100% obtained in MS medium containing 0.1 mg /L IBA within 13 days of inoculation. (Fig. 4).In the present investigation good rooting response was visualized from nodal explants in MS medium and observed that highest number of roots per shoot was 6 initiates in MS + 0.5 mg/L IBA containing medium and highest average length of root per shoot was 8cm found in 0.1 mg/L IBA containing MS medium [34] found that root was induced from shoots on B5 medium with indole butyric acid (IBA. 14 7Um) [35] reported that thidiazuron (TDZ) functions as cytokinins (to produce the shoots) and auxins (to produce the roots) on various explants depending on the basal medium used (Fig. 5).

Fig. (4). Rooting of in vitro regenerated multiple shoots of Glycine Max (BARI- 5 varieties) on IBA containing MS medium.

Fig. (5). Rooting of in Vitro regenerated multiple shoots of Glycine Max (BARI- 5 varieties) on IBA containing the 1/2MS medium.

Fig. (6). In vitro micro plant establishment in a pot after 2.5 months.

CONCLUSION

In vitro micro propagation technique exploits the concept that detached plant (organ Tissue etc.) (Fig. 6).Are totipotent and capable of regenerating the whole plant and allows for a rapid low volume and high yield multiplication system under diseases free condition. It has been effectively used to conserve a variety of plant genotypes. Combination and concentration of plant growth regulators affect regeneration from in vitro cultures of soybean tissue culture has been reported using immature cotyledons hypocotyls and ovaries Primary leaf tissues hypocotyls and epicotyl and cotylidonary nodes of few days germinated seedlings. As demands increase for soybean oil and protein, the improvement of soybean quality and production through genetic transformation and functional genomics becomes an important issue throughout the world. Modern genetic analysis and improvement of soybean heavily depend on an efficient regeneration and transformation process, especially commercially important genotypes. The transformation techniques developed until now till date do not allow high throughout analyses in soybean functional genomics; though significant improvements have been made in the particle bombardment of embryogenic culture and Agrobacetrium mediated transformation of the cotyledonary node over the past three decades. However, routine recovery of transgenic soybean plants using either of these two transformation systems has been restricted to a few genotypes with no reports of transformation on other locally available commercial genotypes. Therefore, development of an efficient and consistent transformation protocol for other locally available commercial genotypes will greatly aid soybean functional genomics and transgenic technology. Considerable and detailed knowledge has been gathered about commercial plant species and some genetic improvement has been achieved. However, in Bangladesh very little is known about variation patterns. Usefulness, and adaptability to this environmental condition of this plant.

ETHICS APPROVAL AND CONSENT TO PARTICIPATE

Not applicable.

HUMAN AND ANIMAL RIGHTS

No animals/humans were used for studies that are the basis of this research.

CONSENT FOR PUBLICATION

Not applicable.

AVAILABILITY OF DATA AND MATERIALS

Not applicable.

FUNDING

None.

CONFLICT OF INTEREST

The authors declare no conflict of interest, financial or

otherwise.

ACKNOWLEDGEMENTS

Decleared none.

REFERENCES

[1] Onwueme IC, Sinha TD. Field Crop Production in Tropical Africa. England: Michael Health Ltd. 1999; pp. 402-14.
[2] Charles A, Guy L. Food biochemistry. Gaitheasburg, Maryland: Aspen Publishers Inc. 1999; pp. 39-41.
[3] Adelakun OE, Duodu KG, Buys E, Olanipekun BF. The potential use of soybean flour (Glycine max) in food fortification.Soybean - Bio-Active Compounds, Prof. InTech 2013.
[4] Schmutz J, Cannon SB, Schlueter J, et al. Genome sequence of the palaeopolyploid soybean. Nature 2010; 463(7278): 178-83.
[5] Severin AJ, Cannon SB, Graham MM, Grant D, Shoemaker RC. Changes in twelve homoeologous genomic regions in soybean following three rounds of polyploidy. Plant Cell 2011; 23(9): 3129-36.
[6] Haerizadeh F, Wong CE, Bhalla PL, Gresshoff PM, Singh MB. Genomic expression profiling of mature soybean (Glycine max) pollen. BMC Plant Biol 2009; 9: 25.
[7] Haerizadeh F, Wong CE, Singh MB, Bhalla PL. Genome-wide analysis of gene expression in soybean shoot apical meristem. Plant Mol Biol 2009; 69(6): 711-27.
[8] Choi H-K, Mun J-H, Kim D-J, et al. Estimating genome conservation between crop and model legume species. Proc Natl Acad Sci USA 2004; 101(43): 15289-94.
[9] Phan HTT, Ellwood SR, Adhikari K, Nelson MN, Oliver RP. The first genetic and comparative map of white lupin (Lupinus albus L.): Identification of QTLs for anthracnose resistance and flowering time, and a locus for alkaloid content. DNA Res 2007; 14(2): 59-70.
[10] Tullu A, Tar’an B, Warkentin T, Vandenberg A. Construction of an intraspecific linkage map and QTL analysis for earliness and plant height in lentil. Crop Sci 2008; 48(6): 2254-64.
[11] Jung C-H, Wong CE, Singh MB, Bhalla PL. Comparative genomic analysis of soybean flowering genes. PLoS One 2012; 7(6)e38250
[12] Shan Z, Raemakers K, Tzitzikas EN, Ma Z, Visser RGF. Development of a highly efficient, repetitive system of organogenesis in soybean (Glycine max (L.) Merr). Plant Cell Rep 2005; 24(9): 507-12.
[13] Mante S, Scorza R, Cordts J. A simple, rapid protocol for adventitious shoot development from mature cotyledons of glycine max cv bragg. In Vitro Cell Dev Biol 1989; 25(4): 385-8.
[14] Sairam RV, Franklin G, Hassel R, et al. A study on the effect of genotypes, plant growth regulators and sugars in promoting plant regeneration via organogenesis from soybean cotyledonary nodal callus. 2003.
[15] Ma X-H, Wu T-L. Rapid and efficient regeneration in soybean [Glycine max (L.) Merrill] from whole cotyledonary node explants. Acta Physiol Plant 2008; 30(2): 209-16.
[16] Wright MS, Ward DV, Hinchee MA, Carnes MG, Kaufman RJ. Regeneration of soybean (Glycine max L. Merr.) from cultured primary leaf tissue. Plant Cell Rep 1987; 6(2): 83-9.
[17] Wright MS, Williams MH, Pierson PE, Carnes MG. Initiation and propagation of Glycine max L.Merr.: Plants from tissue–cultured epicotyls. Plant Cell Tissue Organ Cult 1987; 8(1): 83-90.
[18] Kim J, LaMotte CE, Hack E. Plant regeneration in vitro from primary leaf nodes of soybean (Glycinemax) seedlings. J Plant Physiol 1990; 136(6): 664-9.
[19] Dan Y, Reichert NA. Organogenic regeneration of soybean from hypocotyl explants. in vitro Cell Dev Biol Plant 1998; 34(1): 14-21.
[20] Yoshida T. Adventitious shoot formation from hypocotyl sections of mature soybean seeds. Breed Sci 2002; 52(1): 1-8.
[21] Tiwari MT. Epigenesis and high-frequency plant regeneration from soybean (glycine max (l.) merr.) hypocotyls. Plant Tissue Culture 2003; 13: 61-73.
[22] Radhakrishnan R, Ramachandran A, Kumari BDR. Rooting and shooting: Dual function of thidiazuron in in vitroregeneration of soybean (Glycine max. L). Acta Physiol Plant 2009; 31(6): 1213-7.
[23] Murashige T, Skoog F. A revised medium for rapid growth and bioassays with tobacco tissue cultures. Physiol Plant 1962; 15: 473-97.
[24] Sarkar , et al. American International Journal of Research in Formal, Applied &. Nat Sci 2015; 12(1): 10-3.
[25] Bharti Sahu and Vijaya Koche. In vitro plantlets regeneration of terminalia bellirica roxb. an important medicinal tree.
[26] Mohammad KIS, Miskat AAJ, Roy CK, et al. In vitro Shoot micro propagation of medicinal applications and ornamental value of Cestrum nocturnum L. Indian J Sci Technol 2016; 9(15)
[27] Skoog F, Miller CO. Chemical regulation of growth and organ formation in plant tissues cultured in vitro. Symp Soc Exp Biol 1957; 11: 118-30.
[28] Radhakrishnan R, Ranjitha Kumari BD. Callus induction and plant regeneration of Indian soybean via half seed explant culture. Agric Technol Thail 2007; 3(2): 287-97.
[29] Thao NP, Thu NB, Hoang XL, Van Ha C, Tran LS. Differential expression analysis of a subset of drought-responsive GmNAC genes in two soybean cultivars differing in drought tolerance. Int J Mol Sci 2013; 14(12): 23828-41.
[30] Kim YJ. Factors effecting organogenesis from manure cotyledon explants and regulation in in soybean. J Plant Biotechnol 2014; 6: 39-43.
[31] Cheng TY, Voqui H, Dinh TH. Plant regeneration frob soybean cotyledonary node segment in culture. Plant Sci Lett 1980; 19(2): 91-9.
[32] Franklin1 G, Carpenter1 L, Davis E, et al. Factors influencing regeneration of soybean from mature and immature cotyledons Plant Growth Regul 2004; 43(1): 73-9.
[33] Henrique A, Campinhos EN, One EO, Pinho SZD. effect of plant growth regulators in the rooting of pinus cuttings effect of plant growth regulators in the rooting of pinus cuttings 2006; 49: 1516-8931.
[34] Ranjitha kumari BD, Settu A, Sujatha G. Agrobacterium-mediated genetic transformation in soybean (Glycine max (L.) Merr). J Plant Cell Biotech Mol Biol 2005; 5(3&4): 165-8.
[35] Radhakrishnan R, Ranjitha Kumari BD. Rooting and shooting: dual function of thidiazuron in in vitro regeneration of soybean (Glycine max. L.) acta physiologiae plantarum 2009; 31(6): 1213-7.
